CNC Tube Perforating Machine Punch Die For Φ19.05 Copper Tube Punching Hole
Product Specifications
Attribute |
Value |
Product Name |
Punching Machine Punch Die Punching Hole Tools |
Material |
SKD11, DC53 or HSS SKH51 |
Process Tube Diameter |
Φ9.52-Φ110 |
Processing |
Precision CNC Lathe Turning |
Heat Treatment |
HRC 60°-62° |
Punching Hole Diameter |
Φ5 to Φ22.22 (multiple standard sizes available) |
Quality |
100% Inspection |
Surface Finish |
Ra 0.4 |
Service |
OEM or ODM |
Applications |
CNC Hole Punching Machines, Tube Perforating Machines, Integrated Tube Processing Systems |
Usage |
Punching holes in copper, aluminum, and stainless steel tubes |
Product Description
This precision punching die is essential for producing tube components used in air conditioning and refrigeration heat exchangers. The complete die set includes punch head, punch sleeve, punch pusher, chuck, clamp die, push rod, and hollow tube components, all manufactured from durable SKH51 high-speed steel for exceptional hardness and wear resistance.
Designed for mass production of flute-shaped tubes and tube-forming operations including bending, expanding, and punching. Compatible with fully automated machines from OMS, JDM, and other major manufacturers. Custom configurations available to meet specific production requirements.
Standard Size Combinations
Process Tube Diameter: Φ9.53mm (3/8") to Φ111.12mm (4-3/8")
Punching Hole Diameter: Φ5mm to Φ22.22mm (multiple combinations available)
Custom specifications available upon request.
Product Images
Application Industries
Manufacturing Capabilities
Guangzhou Runshi Mold Co., Ltd. specializes in precision machinery manufacturing, providing equipment molds, vulnerable parts, and cutting tools for air conditioning and heat exchanger production. Our expertise extends to ceramic and tungsten steel components for industries including new energy, medical devices, aerospace, automotive, and semiconductor manufacturing.
